ESD SP5.1.3-2022

The objective of this standard practice is to establish an alternative method for selecting pin pairs used in human body model testing as described in ANSI/ESDA/JEDEC JS-001.
NOTE: The results obtained by applying this standard practice may or may not be identical to the results obtained by applying ANSI/ESDA/JEDEC JS-001 using Table 2A or Table 2B.

The pin pair combinations randomly selected as per this standard practice can be used as an alternative to Table 2A or Table 2B combinations in ANSI/ESDA/JEDEC JS-001 for testing components and microcircuits according to their susceptibility (sensitivity) to damage or degradation by exposure to a defined human body model (HBM) electrostatic discharge (ESD).

Published:

2023

ISBN(s):

1585373494

ANSI:

ANSI Approved

Number of Pages:

19

File Size:

1 file , 920 KB

Note:

This product is unavailable in Russia, Ukraine, Belarus
