SMPTE 2082-0

Document Overview

The SMPTE ST 2082 suite of documents defines the mapping ofvarious source image formats onto a singlelink, dual-link andquad-link serial digital interface operating at a nominal rate of12 Gb/s. This informative "overview" describes the documents in theSMPTE ST 2082 suite.

The SMPTE ST 2082 series specify a common virtual interface thatis carried on both electrical and optical physical interfaces whichare also defined in the document suite.

The diagram of Figure 1 illustrates a simplified ‘Image mappingdata flow' overview for the 12G-SDI profile as defined by the ST2082 document suite. The individual roadmaps of the SMPTE ST 2082standards include full details of reference standards.

Edition:

15

Published:

02/04/2015

Number of Pages:

4
